The CCD camera converts pixels into digital values to deliver precise, high-quality images. The proprietary dispensing software confirms workpiece presence and placement and automatically adjusts as in-process variations occur.
“With working envelopes that range from 400 mm to 800 mm and unlimited workpiece payloads, the GV Series is ideal for precision fluid dispensing onto substrates requiring large work envelopes while not sacrificing repeatability,” said Johnathan Titone, Product Line Specialist – Automated Dispensing Systems, Nordson EFD. “It’s designed to work as a standalone system or an automated solution, and easily integrates into rotary tables or conveyer-fed automation.”
Other benefits of the system include market-leading dimensional positioning accuracy and deposit placement repeatability at +/- 0.02 mm for the 400 mm gantry robot and +/- 0.01 mm for the 800 mm gantry robot. This provides exceptional product quality and reduces rework, rejects, and fluid waste. Intuitive software and vision streamlines training of in-house operators for faster setup and higher productivity.
Nordson EFD designs and manufactures precision fluid dispensing systems for benchtop assembly processes and automated assembly lines. By enabling manufacturers to apply the same amount of adhesive, lubricant or other assembly fluid to every part, every time, EFD dispensing systems are helping companies in a wide variety of industries increase throughput, improve quality, and lower their production costs. Other fluid management capabilities include high-quality syringe barrels and cartridges for packaging one- and two-component materials, along with a wide variety of fittings, couplers and connectors for controlling fluid flow in medical, biopharmaceutical and industrial environments. The company is also a leading formulator of specialty solder pastes for dispensing and printing applications in the electronics industry.
Source: Nordson EFD
