Injection moulding machine Arburg Allrounder 2000 T 2000-800

No. 137732

Type of offer::: Selling
Price:: not specified
Available quantity:: 2 pc
Condition:: Second hand
Year:: 2020
Manufacturer:: Arburg
Clamping force [kN]:: 2000
Valid for:: year
User:: bernhard
Company:: Maschinenhandel Borowski GmbH
Name and surname:: Benjamin / Jan Borowski
Contact:

warehouse no.:    503618
manufacturer:    ARBURG
type:    Allrounder 2000 T 2000-800
controller:    Selogica direct
year of construction:    2020
operation hours:    8344 h

technical data clamping unit
clamping force:    2000    kN
of mould plates h x v:    1772 x 800    mm
min. mould height:    400    mm
max. open daylight:    900    mm
opening stroke:    500    mm
round table diameter:    2000    mm
ejector stroke:    175    mm
ejector force:    45    kN
weight of mould:    6000    kg

technical data injection unit
screw diameter:    50    mm
swept volume:    392    ccm
injection pressure:    2000    bar
screw length:    20    l/d
screw stroke:    200    mm
screw speed:    60    min
screw torque:    880    N
number of heating zones:    8
nozzle stroke:    400    mm

measures & weight
measures of machine l x w x h:    4.11m x 2.65m x 4.81m
total weight:    22000KG

equipment included
screen text german
screen text english
CEE-socket 16A
core pulling hydraulically 4x
air valve 1x
machine incl. water flow regulator
machine without material hopper
Anti vibration mounts
interface robot EUROMAP 67
interface EUROMAP 73
interface OPC
