Arburg Allrounder 1200 T 1000-170 - 503459

ARBURG Allrounder 1200 T 1000-170


warehouse no.:    503459
manufacturer:    ARBURG
type:    Allrounder 1200 T 1000-170
controller:    Selogica
year of construction:    2013
operation hours:    22420 h

ARBURG rotary table machine model ALLROUNDER 1200 T 1000-170 with vertical plasticizing

During the inspection, it was determined that the cylinder no longer met our quality standards.
This means that you have the choice between a 25, 30, or 35 mm unit.
This will be purchased individually for you.

Clamping force: 1000 kN
Plasticizing diameter: 20 mm
Table diameter: 1200 mm
Thermoplastic processing
3-station rotary table rotating 3 x 120° clockwise with servo-electric drive and hydraulic locking pin for fine centering of the rotary plate in the end position; protective separation between the closing and insertion area, the protective parts on the rotary plate must be adapted to the height of the lower mold parts, media connections for the lower mold parts are located in the center of the rotary plate; for the supply of media to the lower mold parts, a suitable rotary union or slip ring transmitter must be provided
Technology level 2 - servo-controlled hydraulic system with two control pumps for regulated machine movements, with distance-dependent, regulated target ramps. The build-up of clamping force is programmable and controlled.
The clamping force is servo-controlled by the second pump. The build-up of nozzle system force is programmable. The system force is manually adjustable and the value is kept controlled. This technology level is a prerequisite for simultaneous movements of the nozzle, ejector, and optional core pulls. Including equipment package for "Extended Movements!"

technical data clamping unit
clamping force:    1000    kN
min. mould height:    400    mm
max. open daylight:    700    mm
opening stroke:    300    mm
round table diameter:    1200    mm
ejector stroke:    175    mm
ejector force:    25    kN
centering diameter of moving platen:    125    mm
centering diameter of fixed platen:    125    mm
weight of mould:    1150    kg

technical data injection unit
screw diameter:    20    mm
swept volume:    31    ccm
injection pressure:    2500    bar
screw length:    25    l/d
screw stroke:    120    mm
number of heating zones:    4
nozzle stroke:    210    mm

measures & weight
measures of machine l x w x h:    4.2m x 2.1m x 0m
total weight:    7300KG

equipment included
3x control for hotrunner
screen text german
CEE-socket 16A
complact flash drive
rotary table
freely programmable inputs (2) and outputs (2)
machine with material hopper
machine incl. water flow regulator
Hydraulically actuated needle shut-off-nozzle
interface robot EUROMAP 67
Servomotor pump drive Energy-saving drive
wear-resistant injection unit
