Complete bubble wrap production line – perfect condition FV 23

Complete bubble wrap production line – perfect condition | 2022 | 23% VAT invoice

We offer for sale a complete, fully automatic production line for bubble wrap (bubble wrap), designed for continuous operation in an industrial environment. The machine is in excellent condition, regularly used, and ready for immediate start-up.

Year of production: 09/09/2022
Sales document: VAT invoice 23%

Basic production capabilities

Maximum foil width: 1200 mm
Roll length: any, up to 250 m
Production of 2-layer bubble wrap
Weight range: 25–300 g/m²
Possibility of producing flat PE foil as well
Working with primary granulates and regranulates (recycled material)

Water system cooling tower included.

The main elements of the production line
Main Extrusion System

Snail: Φ75 × 32
Engine power: 22 kW
Inverter: 22 kW
Gear
Screw material: 38CrMoAlA
Heating zones: 5
Heating power: 26 kW
Heating connector: 1 zone

Hydraulic, automatic filter replacement

Hydraulic filter changer
Automatic, quick replacement

Suitable for recycled materials
Stable operation without production downtime

T-die head

For the production of 2-layer bubble wrap
1-layer flat PE foil
Aluminum heating plates
Special design of the flow chamber – improved film quality
Heat treatment to extend service life
Induction hardening – hardness > 50 HRC
Heating zones: 6
Heating power: 18 kW

Bubble forming rollers

Roller No. 1

Diameter: 270 mm
Bubble size: 10 mm
Surface: hard chrome
Forming: vacuum
Cooling: water, double-sided

Roller No. 2 (additional)

Diameter: 270 mm
Bubble size: 30 mm
Surface: hard chrome
Forming: vacuum
Water cooling – double-sided

Extremely simple roller change system - mechanical ramp.

Automatic raw material feeding system

Materials: LDPE / LLDPE
Capacity: up to 250 kg/h
Automatic empty tank alarm
Temperature control system
Energy-saving design
Ammeters
Precise temperature controls

Automatic winder and cutter

PLC control + touch panel
Automatic cutting after reaching the set length
Self-regulating torque – even and compact windings
Easy handling of ready-made rolls

Online Edge Recycler (3.2 kW)

Shredding the side scraps of foil
Immediate return of material to the hopper
No raw material losses

Power supply 380 V / 50 Hz

Machine dimensions 7 m × 2 m × 2.5 m

The structure is placed directly on the floor

Additional equipment included

Spare parts package from the manufacturer
Consumables:
ceramic foil cutting knives
additional heaters
filters

Additional devices for sale
Professional cooling unit – Water Chiller - PLN 15,000

Uniflair (Schneider Electric) – perfect condition
Precise temperature control - electronic
2 × Scroll compressor
Refrigerant: R410A
2 inverter-controlled fans
Lowara water/glycol pump
Insulated tank 100 l
Expansion tank

Vertical Mixer with Dryer - PLN 8,000

Capacity: 500 kg
Drying function
Even mixing function
Perfect for working in high humidity conditions

Core cutting machine - PLN 1,000

For a determined buyer – the opportunity to purchase a WHOLE READY-MADE BUSINESS

For seriously interested investors, we offer a complete, functioning business model for sale, including:

complete production line,
ready-made sales model,
customer base,
full production and commercial know-how,
real opportunity to start your business immediately.

I will be happy to answer any questions by phone.
The machine is available for inspection by appointment.
