Ssf 720 -S servo injection molding machine
No. 118291
- Type of offer::
- Selling
- Price:
- ~20 834 EUR / pc
- Available quantity:
- 2 pc
- Condition:
- New
- Year:
- 2020
- Manufacturer:
- Others
- Clamping force [kN]:
- 720
- Total power installed [kW]:
- 18
- Valid for:
- 11 days
-
- User:
- technikplast
- Company:
- Technikplast Michał Wiśniewski
- Name and surname:
- Michał Wiśniewski
- Contact:
I offer a new SHUANSHENG injection molding machine with clamping force 720 kN, servo drive
- model SSF-720
- screw diameter - 32/34/36 mm
- shot weight - 102/116/130 g
- L / D ratio - 22.3 / 21.1 / 19.8
- injection pressure - 231/180/160 bar
- injection efficiency - 89/115/129 g / s
- screw rotations - 200 o / min
- hydraulic ejector
- hydraulic core
- pneumatic ejector - 4 pcs - fully programmable
- closing force - 520 kN
- opening stroke - 300 mm
- clearance between the columns - 330 x 330 mm
- minimum mold height - 130 mm
- maximum height of the mold - 360 mm
- ejector force - 31 kN
- ejector stroke - 85 mm
- engine power - 12 kW
- machine dimensions - 3.9 x 1.2 x 1.85 m
- maximum pressure in the system - 140 bar
- heaters power - 6 kW
- amount of oil -130 l
- weight - 2.8 T
