Ssf 520 -S servo injection molding machine (118290)

Type of offer::
Selling
Price:
~15 479 EUR / pc
Condition:
New
Year:
2020
Manufacturer:
Other
Clamping force [kN]:
520
Total power installed [kW]:
12.2
Valid for:
8 days

User:
technikplast
Company:
Technikplast
Name and surname:
Michał Wiśniewski
Contact:

I offer a new SHUANSHENG injection molding machine with a clamping force of 520 kN, a servo drive

  • model SSF-520
  • screw diameter - 25/28/32 mm
  • shot weight - 51/64/84 g
  • L / D ratio - 22.6 / 20 / 17.7
  • injection pressure - 265/211/162 bar
  • injection capacity, - 39/48/65 g / s
  • screw rotations - 200 o / min
  • hydraulic ejector
  • hydraulic core
  • pneumatic ejector - 4 pcs - fully programmable
  • closing force - 520 kN
  • opening stroke - 270 mm
  • clearance between columns - 300 x 300 mm
  • minimum mold height - 100 mm
  • maximum height of the mold - 340 mm
  • ejector force - 25 kN
  • ejector stroke - 75 mm
  • engine power - 7.5 kW
  • machine dimensions - 3.3 x 1.1 x 1.6 m
  • maximum pressure in the system - 140 bar
  • heaters power - 4.7 kW
  • amount of oil -115 l
  • weight - 2.2 T
