Battenfeld HM 8000 P2/ 5400 B4 injection molding machine
No. 133052
- Type of offer::
- Selling
- Price:
- not specified
- Available quantity:
- 1 pc
- Condition:
- Second hand
- Year:
- 2004
- Manufacturer:
- Battenfeld
- Clamping force [kN]:
- 8000
- Valid for:
- 12 hours
-
- User:
- technikplast
- Company:
- Technikplast Michał Wiśniewski
- Name and surname:
- Michał Wiśniewski
- Contact:
Used Battenfled 8000/ 5400 B4 injection molding machine
Possibility of trials, machine at work.
Clamping force 8000 kN
Opening stroke 1175 mm
Mold height min/max 450-950 mm
Clearance between boards 2125 mm
Clearance between columns 1310 x 1210 mm
Screw diameter 100mm
Injection pressure 1613 bar
Injection volume 3338 cc
PS injection weight 3038 g
PE injection weight 2370 g
Plasticizing speed 190 min-1
2 x hydraulic core
2 x air valve
Euromap 67 for the robot
