Battenfeld HM 10000 P2/ 9200 B4 injection molding machine

No. 133051
Type of offer::
Selling
Price:
not specified
Available quantity:
1 pc
Condition:
Second hand
Year:
2004
Manufacturer:
Battenfeld
Clamping force [kN]:
10000
Valid for:
-15 minutes

User:
technikplast
Company:
Technikplast Michał Wiśniewski
Name and surname:
Michał Wiśniewski
Contact:

Used Battenfeld 10000 P2/ 9200 B4 injection molding machine

Year of production 2004, possible to check.

Clamping force10,000 kN

opening stroke 1300 mm

Mold height min/max 500-1050 mm

Clearance between boards 2350 mm

Clearance between columns 1610 x 1330 mm

Screw diameter 100mm

Injection pressure 1613 bar

Injection weight 4 kg for PP 5 mfi

Plasticizing speed 190 min-1

2 x hydraulic core

2 x pneumatic valve

8 x hot runner (mold heating)

Euromap 67 for the robot
