New CNC lathe FCL-450TMS with sub-spindle

The offer concerns a new Taiwanese CNC lathe, universal, twin-spindle FCL-450TMS with sub-spindle, offered by RICHO Polska.

Lathe installation and operator training are included in the machine price.

Max. turning diameter: 245 mm
Max. turning length: 260 mm
Spindle bore: 56 mm
Max. spindle speed: 6,000 rpm
Spindle power: 11 kW
Number of spindles: 2
Number of tools in turret: 12 pcs.
Control system: FANUC
Rated motor power: 11 kW
Machine dimensions: L 3,750 mm, W 2,000 mm, H 2,000 mm
Machine weight: 4,550 kg

Standard equipment:
Fanuc 0i-TD or 18i-TB control system.
12-position servo tool turret, tool change time 0.6 s, turret rotation in both directions.
Hydraulic unit powering the chuck, tailstock and spindle brake.
Through-hole chuck.
Spindle brake.
Cooling system with high-pressure pump.
Ventilated electrical cabinet.
Toolbox.
Work lighting.
Automatic lubrication.
Three-color signal lamp.
Chip conveyor with tank.
Transformer.
Technical and Operation Documentation.
CE certificate.

Optional equipment:
Tool measurement for main spindle and sub-spindle.
Bar feeder.
Part cut-off detection.
Part unloading for main spindle and sub-spindle.
Part steady rest.
Robot - automatic part loading and unloading.
Carriage anti-collision system.

Price: on request.

All published data and information are for reference only and do not constitute a commercial offer within the meaning of Article 66 of the Polish Civil Code.
